S Series Right Angle Helical Worm Geared Motor with Hollow Shaft
Product Description:
S Series Right Angle Helical Worm Geared Motor with Hollow Shaft
Product Feature
1. Highly modular design: It can be easily equipped with various types of motors or other power inputs. The same model can be equipped with motors of multiple powers. It is easy to realize the combined connection between various models.
2. Transmission ratio: fine division and wide range. Combined models can form a large transmission ratio, that is, output extremely low speed.
3. Installation form: the installation location is not restricted.
4. High strength and small size: the box body is made of high-strength cast iron. The gears and gear shafts adopt the gas carburizing quenching and fine grinding process, so the load capacity per unit volume is high.
5. Long service life: Under the conditions of correct model selection (including the selection of appropriate use coefficient) and normal use and maintenance, the life of the main parts of the reducer (except for wearing parts) is generally not less than 20,000 hours. The wearing parts include lubricating oil, oil seals, and bearings.
6. Low noise: The main parts of the reducer have been precision processed, assembled, and tested, so the reducer has low noise.
7. High efficiency: the efficiency of a single model is not less than 95%.
8. It can bear a larger radial load.
9. Can bear axial load not more than 15% of radial force.
Model:
S37 、S47 、S57、 S67、 S77、 S87、 S97
Main Technical Features:
Output Speed (r/min)：0.06-379
Output Torque (N. m): 22264 highest
Motor Power (Kw) : 0.12-110
